$36.00The Story
The Double Wall Fixed Elbows are available in 45 and 90 degree angles. The elbows are nonadjustable. Manufactured with heavy duty 24 gauge steel with a 430 stainless steel inner. Compatible with our black stove pipe along with Ventis, Champion, and Nexvent
Offset Charts:
45 Degree Offset Chart
| Pipe Length | 6" Dia.: A Offset | 6" Dia.: B Height | 7" Dia.: A Offset | 7" Dia.: B Height | 8" Dia.: A Offset | 8" Dia.: B Height |
|---|---|---|---|---|---|---|
| 0" | 6 3/8" | 15 1/8" | 6 3/8" | 15 1/8" | 6 3/8" | 15 1/8" |
| 6" | 9" | 17 5/8" | 9" | 17 5/8" | 9" | 17 5/8" |
| 12" | 13 1/4" | 21 7/8" | 13 1/4" | 21 7/8" | 13 1/4" | 21 7/8" |
| 18" | 17 1/2" | 26 1/8" | 17 1/2" | 26 1/8" | 17 1/2" | 26 1/8" |
| 24" | 21 3/4" | 30 3/8" | 21 3/4" | 30 3/8" | 21 3/4" | 30 3/8" |
| 36" | 30 1/4" | 38 3/4" | 30 1/4" | 38 3/4" | 30 1/4" | 38 3/4" |
| 48" | 38 3/4" | 47 1/4" | 38 3/4" | 47 1/4" | 38 3/4" | 47 1/4" |
| 60" | 47 3/8" | 55 3/4" | 47 3/8" | 55 3/4" | 47 3/8" | 55 3/4" |
| 72" | 55 7/8" | 64 1/8" | 55 7/8" | 64 1/8" | 55 7/8" | 64 1/8" |
| 84" | 64 3/8" | 72 5/8" | 64 3/8" | 72 5/8" | 64 3/8" | 72 5/8" |
90 Degree Offset Chart
| Pipe Length | 6" Dia.: A Offset | 6" Dia.: B Height | 7" Dia.: A Offset | 7" Dia.: B Height | 8" Dia.: A Offset | 8" Dia.: B Height |
|---|---|---|---|---|---|---|
| 0" | 12 3/4" | 14 3/4" | 12 3/4" | 15 3/4" | 12 3/4" | 16 3/4" |
| 6" | 17 5/16" | 14 3/4" | 17 5/16" | 15 3/4" | 17 5/16" | 16 3/4" |
| 12" | 23 5/16" | 14 3/4" | 23 5/16" | 15 3/4" | 23 5/16" | 16 3/4" |
| 18" | 29 1/8" | 14 3/4" | 29 1/8" | 15 3/4" | 29 1/8" | 16 3/4" |
| 24" | 35 5/16" | 14 3/4" | 35 5/16" | 15 3/4" | 35 5/16" | 16 3/4" |
| 36" | 47 5/16" | 14 3/4" | 47 5/16" | 15 3/4" | 47 5/16" | 16 3/4" |
| 48" | 59 5/16" | 14 3/4" | 59 5/16" | 15 3/4" | 59 5/16" | 16 3/4" |
*Due to many variables beyond our control, the installer should check actual parts for final dimensions.
Measurement Charts:
45 Degree Elbow
| Elbow Size | A | B | C | D |
|---|---|---|---|---|
| 6” | 6” | 7” | 10.5” | 9” |
| 7” | 7” | 8” | 11.2” | 10” |
| 8” | 8” | 9” | 12” | 11” |
90 Degree Elbow
| Elbow Size | A | B | C |
|---|---|---|---|
| 6” | 6” | 7” | 10.5” |
| 7” | 7” | 8” | 11.75” |
| 8” | 8” | 9” | 12.75” |
*Due to many variables beyond our control, the installer should check actual parts for final dimensions.
